Amplificador Estereo Integrado Denon Pma-1700 Ne 140w 220v

Descripción

SONIDO PAUL
Amplificador Estereo integrado Denon Denon PMA-1700NE 140w
Made in Japon

Technical Information
General
Specifications
Analog
Audio
Power Amplifier Circuit New UHC-MOS
Single Push Pull (7)
Pre Amplifier Circuit Variable Gain Preamplifier (OP AMP)
Bass / Treble / Mid / Balance Control Yes / Yes / - / Yes
Source Direct Yes
Analog Amp Mode Yes (button on front panel)
Digital
Audio
DAC Circuit PCM1795
Digital Processing Advanced AL32 Processing Plus
DAC Master Clock Design Yes
Asyncronous mode (for USB-B input) Yes
Audio
Rated Output Power
70W + 70W
(8ohm,20Hz-20kHz,THD0.07%)
140W + 140W
(4ohm, 1kHz, THD0.7%)
Total Harmonic distortion 0.01 % (Rated output: –3 dB),
8 ohm/ohms, 1 kHz"
Input Sensitivity: Phono input MM: 2.5 mV / 47 kohm
MC: 200 V / 100 ohm
Input Sensitivity:
CD/LINE/RECORDER 125 mV / 19 kohm
Input Sensitivity: Power Amp input 0.85V / 47kohm (EXT. PRE)
Signal to Noise Ratio
PHONO (MM): (89dB)
PHONO (MC): (74dB)
CD: (107dB)
Power
Consump.
Power Consumption 295W
at Standby 0.2W TV autoplay off
0.4W TV autoplay on
Audio Feature
Audio
Video
Phono Input Yes (MM / MC)
Analog Input (include Phono) /
REC Out (RCA)
4/1 (PHONO / CD / NETWORK, AUX/
RECORDER)
Optical input / output
(Maximum Support) 2 / 0 (192kHz/24bit)
Coaxial input / output
(Maximum Support) 1 / 0 (192kHz/24bit)
Speaker Terminal Gold Plated
Headphone Output 1 (Turn off the speaker when
inserting headphone)
Control
Remote Control RC-1249
Remote Control Bus Terminal Yes
Network
Wi-Fi No
HEOS No
USB B
USB B (USB DAC) 1 (Rear)
PCM Sample Rate 384kHz/32bit
DSD Audio Streaming (DoP) 11.2MHz

Garantía del vendedor: 1 años
