Previo De Linea Preamplificador Valvular Air Tight Atc-3

Descripción

Previo de Linea Preamplificador Valvular AIR TIGHT ATC-3

ATC-3 is the most affordable preamp from Air Tight. It will be a perfect companion for all ATM power amps and especially for ATM-1, ATM-2, ATM-300 and ATM-211.

Features include:
- SRPP line amp with reinforced buffer stage to assure good noise rejection, low output impedance and extended linearity,
- Rich power supply featuring quick recovery diode for high operational speed and low pulse noise,
- Single steel sheet with multi-layer enamel for high rigidity and low noise,
- High quality input/output jacks with detachable mains cord.

Specification


Valves employed

12AX7 (ECC83) x 1, 12AU7 (ECC82) x 2

Output Voltage

rated 2V, max. 15V

Output Impedance

200 ohm

THD

less than 0.01%

Input sensivity

110mV (output 1V)

S/N Ratio

90dB (IHF-A weighted)

Dimensions

430 (W) x 325 (D) x 90 (H) mm

Weight

8kg
